LED CANOPY – FOOD & PETROLEUM GRADE
HACCP International Certified Australian Made LED Lighting
The all new Aqualuma Food & Petroleum Grade Canopy Light has been designed for both new builds and retro fitting into food processing facilities, commercial cold stores, fuel station forecourts, and other canopy roofs. The Canopy light allows for ease of installation and can be surface mounted on multiple ceiling types including concrete or sandwich panel. The slim low-profile design requires very low maintenance and continues Aqualuma’s renowned product reliability and energy efficiency.
LED Canopy Features
MADE IN AUSTRALIA
Designed and manufactured in Australia.
5 YEAR WARRANTY
The premium quality LED Canopy Light backed by a 5 year warranty.
SUBSIDIES APPLY
Victorian and NSW rebate subsidies apply. Please contact us for more details.
OUTPUT
Up to 150lm/per watt efficacy.
WATTAGE OPTIONS
This LED Canopy Light comes in 90, 125 and 165 wattage options.
FOOD SAFE
Ideally suited to cold stores and food processing facilities the LED Canopy Light carries Food grade certification.
INSTANT ON/OFF
LED’s do not require any warm up time allowing for instant on/off output and improved energy savings.
IP RATING
The LED Canopy Light is rated at IP65.
MOUNTING OPTIONS
Surface Mount – Slimline (standard)
Allows for a clean visually appealing surface install where the driver can placed upright into the ceiling cavity. Plastic caps are provided to conceal the screw heads once securely tightened.
Stand Off Frame (sold separately)
Allows install into surfaces where surface mount option is not available such as concrete slabs or any material where ceiling access is limited. Stand off frame sold as an optional extra.
SPECIFICATIONS
| 90W | 125W | 165W | ||
| Optical Characteristics | ||||
| Clear – Luminous Flux (Fixture Lumens) | 13,698lm | 17,963lm | 23,096lm | |
|---|---|---|---|---|
| Diffused – Luminous Flux (Fixture Lumens) | lm | lm | lm | |
| CCT | 5000K | 5000K | 5000K | |
| Electrical Characteristics (Luminaire & Power Supply) | ||||
| Power Consumption | 90W | 125W | 165W | |
| Voltage Range | 90 – 277VAC | |||
| Frequency Range | 47 – 63Hz | |||
| Power Factor | > 0.96 | |||
| Leakage Current | < 1mA | |||
| Cable Type |
1.5m cable rated to -40 ⁰ C to 75 ⁰ C (std) |
|||
| Cable Length | 1.5m | |||
| Environmental | |||||
| IP Rating | IP65 | ||||
|---|---|---|---|---|---|
| Operating Temp. Range | -40 ~ +45°C | ||||
| Thermal Management Type | Passive | ||||
| Expected Lifespan | 100,000 Hours to L70 | ||||
| Material Composition (Body) |
6063 T5 aluminium, white powdercoated and polycarbonate componentry |
||||
| Material Composition (Lens) |
Hardened clear or diffused acrylic, UV Polycarbonate, Toughened Glass |
||||
| Weight/Packaging | |||||
| Slimline | with Stand off frame | ||||
| 90/125/165 | 6.5kg | 8kg | |||
| Luminaire Dimensions | L600 x W600 x H34mm | ||||
| Packaging Dimensions | L620 x W 650x H125mm | ||||
| Warranty | |||||
| Warranty | 5 Year Warranty | ||||
COMPLIANCE
| HACCP | HACCP International Certification | |||
|---|---|---|---|---|
| FCC | Tested to comply with FCC Standards | |||
| TUV RHEINLAND | Total Quality Assurance provider | |||
| SAA | AUS & NZ Electrical product safety approval certification | |||
| RCM – C TICK | Complies with the electrical safety and EMC legislative requirements | |||
| CE | Meets the requirements of the applicable EC directives | |||
| ISO:9001 | International standard for a quality management system | |||
