AISLE LED HIGH BAY
(AISLE OPTIC)
Australian Made LED Lighting Solutions
The Aqualuma LED Highbay aisle optic is part of the premium commercial range and is designed specifically to replace traditional metal halide or induction lighting used in indoor and outdoor applications. The Highbay Aisle Optic is optimised to provide a long and narrow beam pattern, which is ideally suited to illuminate tall storage racking in warehouses and distribution centres.
AISLE LED High Bay Features
MADE IN AUSTRALIA
Designed and manufactured in Australia.
10 YEAR WARRANTY
A premium quality LED High Bay backed by a 10 year warranty.
LONG LIFE
Rated at a minimum life of 100,000 hours to 70% residual light output.
OUTPUT
Up to 150lm/per watt efficacy
WATTAGE OPTIONS
This LED High Bay comes in 90, 125, 165 and 185 wattage options. See our High Output LED for more options.
CONTROL OPTIONS
Tailored control options to suit any requirement from daylight harvesting and radio sensors to complete wireless control and monitoring systems.
INSTANT ON/OFF
LED’s do not require any warm up time allowing for instant on/off output and improved energy savings.
IP RATING
The LED High Bay is rated at IP66 allowing for total protection against dust and high pressure water.
MOUNTING & LENS OPTIONS
Ceiling Plate
Bracket
EzyStrut Mount
Eye
Clear / Diffused / Polycarbonate Acrylic
SPECIFICATIONS
| 90W | 125W | 165W | 185W | |
| Optical Characteristics | ||||
| Clear – Luminous Flux (Fixture Lumens) | 13,272 lm | 18,456 lm | 24,828 lm | 26,108 lm |
|---|---|---|---|---|
| Diffused – Luminous Flux (Fixture Lumens) | 12,959 lm | 18,005 lm | 23,282 lm | 25,135 lm |
| CCT | 4000K ~ 5300K | 4000K ~ 5300K | 4000K ~ 5300K | 4000K ~ 5300K |
| Electrical Characteristics (Luminaire & Power Supply) | ||||
| Power Consumption | 90W | 125W | 165W | 185W |
| Voltage Range | 90 – 277VAC | |||
| Frequency Range | 47 – 63Hz | |||
| Power Factor | > 0.93 | |||
| Leakage Current | < 1mA | |||
| Cable Type | Standard 3 Core Flex & Plug / Low Temp Silicone | |||
| Cable Length | 3m | |||
| . | |||||
| Environmental | |||||
| IP Rating | IP66 | ||||
|---|---|---|---|---|---|
| Operating Temp. Range | -40 ~ +45°C | ||||
| Thermal Management Type | Passive | ||||
| Expected Lifespan | 100,000 Hours to L70 | ||||
| Material Composition (Body) | Die-cast Powder Coated Marine Grade Aluminium | ||||
| Material Composition (Lens) | Acrylic or Polycarbonate | ||||
| Weight/Packaging | |||||
| Luminaire | Packaged | ||||
| 90/125/165/185 | 7.5kg | 8.15kg | |||
| Luminaire Dimensions | L406 x W406 x H135mm | ||||
| Packaging Dimensions | L510 x W490 x H190mm | ||||
| Warranty | |||||
| Warranty | Premium 10 Year Warranty | ||||
HOOK EYE
CEILING PLATE
WALL BRACKET
COMPLIANCE
| UL | Classified by UL to UL 1598, UL 8750, CSA C22.2 NO 250.0 | |||
|---|---|---|---|---|
| DLC | DesignLights™ Consortium qualified premium product | |||
| FCC | Tested to comply with FCC Standards | |||
| INTERTEK | Total Quality Assurance provider | |||
| SAA | AUS & NZ Electrical product safety approval certification | |||
| RCM – C TICK | Complies with the electrical safety and EMC legislative requirements | |||
| CE | Meets the requirements of the applicable EC directives | |||
| ISO:9001 | International standard for a quality management system | |||
