LITEBAY LED HIGHBAY

Design and innovation at its best

The Aqualuma LiteBay continues to set industry benchmarks, fulfilling the need for a high-performing alternative within our High bay range. Embodying the spirit of Australian manufacturing, the LiteBay is designed, produced, and warrantied right here on our shores. With unwavering quality and the innovative design that Aqualuma is celebrated for, the 150W LiteBay delivers a remarkable 19,245 lumens.

LED LITEBAY BROCHURE

Litebay Aqualuma

LED Litebay Features

The Aqualuma LED Litebay is proudly Designed and manufactured in Australia.

The Aqualuma LED Litebay is proudly backed by a 7-year warranty.

Rated at a minimum life of 100,000 hours to 70% residual light output

129lm/per watt efficacy

The Aqualuma LED Litebay comes as a 150W option only.

Direct replacement for traditional Metal Halide or Sodium Vapour fittings.

LED’s do not require any warm up time allowing for instant on/off output and improved energy savings.

The LED High Bay is rated at IP66 allowing for total protection against dust and high pressure water.

MOUNTING & LENS OPTIONS

Ceiling Plate

Bracket

EzyStrut Mount

Eye

Clear / Diffused / Polycarbonate Acrylic

SPECIFICATIONS

150W
Optical Characteristics
Clear – Luminous Flux (Fixture Lumens) 19,245lm
Diffused – Luminous Flux (Fixture Lumens) 18,629lm
CCT 5000K (daylight)
Electrical Characteristics (Luminaire & Power Supply)
Power Consumption 150W
Voltage Range 90 – 277VAC
Frequency Range 47 – 63Hz
Power Factor > 0.93
Leakage Current  < 1mA
Cable Type Standard 3 Core Flex & Plug / Low Temp Silicone
Cable Length 3m
Environmental
IP Rating IP66
Operating Temp. Range -40 ~ +45°C
Thermal Management Type Passive
Expected Lifespan 100,000 Hours to L70
Material Composition (Body) Die-cast Powder Coated Marine Grade Aluminium
Material Composition (Lens) Acrylic or Polycarbonate
Weight/Packaging
Luminaire Packaged
150 7.5kg 8.15kg
Luminaire Dimensions L406 x W406 x H135mm
Packaging Dimensions L510 x W490 x H190mm
Warranty
Warranty 7 Year Warranty

HOOK EYE

CEILING PLATE

WALL BRACKET

COMPLIANCE

SAA AUS & NZ Electrical product safety approval certification
RCM – C TICK Complies with the electrical safety and EMC legislative requirements
CE Meets the requirements of the applicable EC directives
ISO:9001 International standard for a quality management system

Downloads

Title File Size Download
 pdf_icon LED LITEBAY  SPECIFICATIONS 3MB download_icon Download
 pdf_icon LED LITEBAY  INSTRUCTION MANUAL 2MB download_icon Download

Need a lighting plan?

Aqualuma offers a lighting design service to ensure that your conversion to energy efficient lighting maintains or improves your current lighting levels.
